Automatic Compact Busbar Assembly Line With Self Checking Functions

Automatic Compact Busbar Assembly Line With Self Checking Functions
Automatic Compact Busbar Assembly Line With Self Checking Functions Automatic Compact Busbar Assembly Line With Self Checking Functions Automatic Compact Busbar Assembly Line With Self Checking Functions

Large Image :  Automatic Compact Busbar Assembly Line With Self Checking Functions

Product Details:
Place of Origin: China
Brand Name: Kiande
Certification: ISO9001
Model Number: KD-ZPX/NC -2D
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: customized
Packaging Details: plywood case
Delivery Time: 45 working days
Payment Terms: L/C, T/T
Supply Ability: 10set/ month
Detailed Product Description
Name: Compact Busbar Manufacturing Machine Max. Busbar Height: 350mm (Single Layer)
Control Axis: 5 Axis Working Efficiency: Around 3000mm/2 Min
Feature: Durable Frame: Aluminum
Power: 380~415VAC 50~60Hz 20kW Max. Busbar Length: 6000mm
Equipment Dimension: L25000mm*W2000mm*H19000mm
High Light:

Compact Busbar Assembly Line

,

20kW Busbar Assembly Line

,

50Hz Busbar Assembly Line

Automatic Compact Busbar Assembly Line With Self Checking Functions



Description



Automatic Busbar assembly line is customized according to clients’ busbar type. It can achieve unmanned operation no matter the busbar is fixed by rivet or bolt. Currently the busbar type is mainly divided into two types: two-piece type and four-piece type.



By automatic assembly and fixing, the automatic assembly machine will help to reduce manpower and improve the product quality and working efficiency. The working principle is to recognize the busbar type and adjust all the parameters in the machine automatically by scanning the bar code. By module interconnection among PLC, network, touch screen and IPC etc., automatic assembly machine can also achieve information communication with ERP, automatic inspection machine and other related machines.



Besides that, automatic assembly machine has self-checking functions by self diagnosing each input and output signal to avoid failures. Furthermore, data statistics for machine’s OEE (comprehensive utilization rate) is helpful for future data analysis.



Equipment data on automatic busbar assembly line



No. Parameters
Model KD-ZDX/NC-2(4)D-6(4.5)

Max. Busbar Height

350mm (Single layer)

Max. Busbar Length

6000mm
Position Type Unilateral position/ Middle position
Working Efficiency Around 3000 mm/2 min
Control Axis 5 Axis

Control System

Network control, Online maintenance (optional)

Riveting Station Nos

sets (Four-piece type)/2 sets (Two-piece type)

Riveting Type Automatic riveting
Power 380~415VAC 50~60Hz 20kW
Equipment Dimension L25000mm*W2000mm*H19000mm



FAQ

Q1: Are you a factory or trading company?
A1: Our factory located in Zhengjiang city which is specialized in busbar assembly equipment and switchgear assembly equipment such as busbar assembly system, busbar testing machine, busbar wrapping machine and busbar accessores. Our sales office located in Suzhou city which traffic is more convinent.

Q2: Where is your factory location? How can I visit there?

A2: Our factory is located in Jiangsu, China, welcome to visit us at any time. You can take the plane to Shanghai and then take the highway to Changzhou Bei Station(1 hour), then we will pick u up.

Q3: How does your factory do regarding quality control?

A3: Quality is priority. We always attach great importance to quality controlling from the beginning to the end. We support to inspect machine before shipment.

Q4: What’s the guarantee if we purchase from you?
A4: All the equipment ordered from us will provide one year guarantee from the delivery date .If there is any wearing part be broken within the warranty and isn’t caused by improperly operation then we would offer the new parts for free.

Q5: How about the after service?
A5: There’s no problem we could send our engineer to install or fix the machine locally in due course but customer need to pay the visa, round air tickets cost and arrange the hotel accommodation for our engineer.

Automatic Compact Busbar Assembly Line With Self Checking Functions 0



Automatic Compact Busbar Assembly Line With Self Checking Functions 1
