Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test

Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test
Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test

Large Image :  Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test

Product Details:
Place of Origin: China
Brand Name: Kiande
Certification: ISO9001
Model Number: KD-JCX/NC-E/H-6
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: Negotiable
Packaging Details: plywood case
Delivery Time: 45 working days
Payment Terms: T/T, L/C
Supply Ability: 10set/month
Detailed Product Description
Name: Busbar Automatic Production Line Power: 380~415VAC 50~60Hz 5kW
Grounding Test: 0~25A Insulation Test: 1~1000V
High Voltage Withstanding Test: 0~5000V Servo Nos: 2 Axis( Z Axis/X Axis)
Busbar Length: 1200mm~6000mm Busbar Height: 100mm~650mm
Equipment Dimension: L12000mm*W1200mm*H1900mm
High Light:

servo drive Busbar machine

,

servo drive Busbar equipment

,

Unilateral Busbar Inspection equipment

Automatic Busbar Inspection Machine with High Voltage Withstanding Insulation Resistance Grounding Test Functions



The main drive part of the machine adopts the popular servo drive form, with novel structure, abundant power and easy operation.No oil pollution for the work area, noise reduction, small occupation area, environmental protection and practical. The output force can reach 350KN, the servo drive easily controllable, and precisely and accurately linked with the PLC. It is enough to realize the functions of fast forward, fast retreat and slow inching, which can improve the processing efficiency and ensure the accuracy of bending, which is unmatched by hydraulic drive machines. Equipped with high-power, large inertia servo motor, optional bending die to achieve horizontal bending, vertical bending, twisting and other processing functions.



Feature

the inspection machine is controlled by PLC and can generate the inspection report which can be printed.

To inspect busbar withstanding voltage value and insulation resistance.



Fuction



HV withstanding test, insulation resistance test and grounding test



Function introduction



Busbar Automatic Production Line is composed of three parts, feeding positioning station, inspection station and discharge station. When the busbar enters the feeding position, the control system will select the right testing fixture to start testing from the information identified by bar code or previous assembly line. Three tests will be performed including HV withstanding test, insulation resistance test and grounding test. After test is finished, testing report will be generated.



Equipment data on automatic busbar inspection line



No. Parameters
Model KD-JCX/NC-E/H-6
Busbar Height 100mm~650mm
Busbar Length 1200mm~6000mm
Busbar Type Straight length type
Position Type Unilateral / Middle

Working Efficiency

2 min/piece(testing time is adjustable.)

Servo Nos 2 axis( Z axis/X axis)

Vision System

Phase error judgment( optional)

Printing System

Bar code printing/ Report printing( optional)

High Voltage Withstanding Test

0~5000V
Insulation Test 1~1000V
Grounding Test 0~25A

Power

380~415VAC 50~60Hz 5kW
Equipment Dimension L12000mm*W1200mm*H1900mm



Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test 0

Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test 1

Automatic Inspection Busbar Machine Servo Drive For HV Withstanding Test 2
