Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly

Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly
Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly
video play

Large Image :  Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly

Product Details:
Place of Origin: CHINA
Brand Name: Kiande
Certification: ISO9001
Model Number: KD-MJQ-2
Payment & Shipping Terms:
Minimum Order Quantity: 1SET
Price: Custmized
Packaging Details: carton box or plywood case
Delivery Time: 30 days
Payment Terms: L/C, T/T
Supply Ability: 100SET/month
Detailed Product Description
Name: Self Piercing Rivet Gun Model: KD-MJQ-2
Max. Pressure: 25MPa Gun Head Stroke: 50mm
Aluminum Thickness: 3mm+3mm Iron Thickness: 1.5mm+1.5mm
Oil Pipe Length: 10000mm Oil Tank Capacity: 50L
High Light:

Busbar Riveting Equipment 250MPa

,

Servo Control Busbar Riveting Equipment

,

Busbar Riveting Machine 250MPa

Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly​



1. No need to drilling holes, no wast and no iron crap occured.
2. Self-piercing processing allowed Non-metallic sandwich material.
3. No thermal stress concentraition and no damage to the surface coating.
4. High dynamic strength and far superior to the traditional welding.
5. Forming by special die with stamping and processed quality is stable.
6. By check the riveting point geometry size can judging the riveting quality.
7. No damage to plating or coating and no need after painting or plating.
8. Application:Automotive metal sheet components.
9. Computer chassis,home appliances metal sheet etc.
10. Elevator's metal sheet and other commercial facilities.
11. Busway's industrial engineering applications.
12. Other metal sheet connect occasion.



Function introduction

Self-piercing riveting machine, also called a riveting gun, is applied for busbar assembly. It can be customized according to different busbar housing. Before riveting, the operator does not need to drill the hole. The machine can realize self-piercing riveting by its pressure and rivet structure. The working principal is as below.



Features:

1, The supercharger drives the split cylinder as the riveting power source, which has the characteristics of low noise, low energy consumption and no pollution.
2, The servo system controls the rivet clamp and the left and right movement, to realize the two sides are simultaneously riveted by the forward movement and the stop action of the roller.
3, The discharge line has a lateral removal function.
4, The busbar casing is no more than 3 meter length.
5, Feeding line has servo clamping mechanism, the most front-end is 3m roller table



Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly 0

Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly 1Busbar Riveting Equipment 250MPa Pressure For Busbar Assembly 2
