Product Details:
Payment & Shipping Terms:
|
Name: | Digital BusBar Booster Machine | Bending Power Type: | Hydraulic And Pneumatic Hybrid |
---|---|---|---|
Die: | Fast Die Change | Workplace Size: | L450mm*W340mm |
Air Source: | 0.6MPa | Equipment Dimension: | L680mm* W580mm* H2600mm |
Pressure: | 40T Or 50T, Max. 80T | Power: | 220~230VAC 50~60Hz 80W |
Model: | KD-YYJ-40(50)T | ||
High Light: | 50T BusBar Booster Machine,50T Busbar Bending Machine,0.6MPa BusBar Booster Machine |
50T Gas-Hydraulic Digital BusBar Booster Machine for Copper Punching
Function introduction
Digital bus bar punching machine is used to punch the two ends of busbar in one time to guarantee parallelism between busbar profile and conductor. This parallelism ensures the reliable connection between conductor and joint which can control joint temperature rising. Key point is that machine can adjust the rebound coefficient according to conductor’s material and width. Rebound coefficient varies by bending or different conductor width and this kind of adjustment can guarantee the parallelism.
Equipment data on digital copper bar punching machine
No. | Parameters |
Model | KD-YYJ-40(50)T |
Bending Power Type | Hydraulic and pneumatic hybrid |
Pressure |
40T or 50T, Max. 80T |
Die | Fast die change |
Workplace Size | L450mm*W340mm |
Control Mode | Digital control |
Air Source | 0.6MPa |
Power | 220~230VAC 50~60Hz 80W |
Equipment Dimension | L680mm* W580mm* H2600mm |
