Auto Wrapping Busbar Trunking System Compact Unilateral Type

Auto Wrapping Busbar Trunking System Compact Unilateral Type
Auto Wrapping Busbar Trunking System Compact Unilateral Type
video play

Large Image :  Auto Wrapping Busbar Trunking System Compact Unilateral Type

Product Details:
Place of Origin: China
Brand Name: Kiande
Certification: ISO9001
Model Number: KD-JCX/NC-E/H -4
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: customized
Packaging Details: plywood case
Delivery Time: 45 working days
Payment Terms: T/T, L/C
Supply Ability: 10set/ month
Detailed Product Description
Name: Machine For Busduct Power: 380 VAC 50~60Hz 3kW
Busbar Height: 100mm~650mm Busbar Length: 500mm~3000mm
Grounding Test: 0~25A Insulation Test: 1~1000V
High Voltage Withstanding Test: 0~5000V Servo Nos: L6200mm*W800mm*H800mm
High Light:

Auto Wrapping Busbar Machine

,

Unilateral Type Busbar Machine

,

Straight Busbar Machine

Auto Wrapping Machine For Compact Busbar Trunking System



Machine for Compact Bubar Short-Circuit Withstand and insulated Testing



  • Increases work efficiency by 10 times with the attached angle indicator, which was newly developed in 2007, to watch the angle of work during bending
  • Convenient manual operation because of the detachable angle indicator
  • Bending of the desired thickness and angle of a bus bar by workers is available during automatic operation.
    (The angle can vary depending on the material of the bus bar. In this case, adjust 1–2° of the folding angle.)



Equipment data on Manual busbar inspection line



No. Parameters
Model KD-JCX/M-4
Busbar Height 100mm~650mm
Busbar Length 500mm~3000mm
Suitable Busbar Type Straight busbar
Position Type Unilateral

Printing System

Bar code printing/ Report printing( optional)

High Voltage Withstanding Test

0~5000V
Insulation Test 1~1000V
Grounding Test 0~25A

Power

380~415VAC 50~60Hz 3kW

Equipment Dimension

L6200mm*W800mm*H800mm
