| Name: | Busbar Punching Machine | Stroke of X Axis : | 1200mm |
|---|---|---|---|
| Speed of X Axis: | 500mm/s | Punching Stroke: | 50mm |
| Distance Accuracy of Two Holes: | ±0.1mm | Max. Hydraulic Force: | 31.5MPa |
Busbar punching machine for bus bar copper aluminum punching
The automatic busbar conductor multifunctional processing machine is a machine with unmanned operation. Operator only needs to set the related data on the touch screen such as current ratings,quantity, hole distance, raw material length and etc. and strip conductors will be processed automatically. This will save labor cost and win stable and good quality. As connection bar type is different in the joint, machine can be customized according to the requirement to proceed hole punching, counter bore, cutting and etc..
this busbar punching machine is used for copper and aluminum busbars with accurate positioning and high reliablity. It is widely used in high and low voltage complete sets, switchgear, transformer manufacturing
Technical parameters
| Force(KN) | Punch | 300 | |
| Stretch | 300 | ||
| Shear | 300 | ||
| Stroke of X Axis | 1200mm | ||
| Max. Speed of X Axis | 500mm/s | ||
| PunchingStroke | 50mm | ||
| Distance Accuracy of Two Holes | ±0.1mm | ||
| Conductor(Aluminum, Copper) | Length | 6000mm | |
| Width | 100mm~140mm | ||
| Thickness | 2mm~4.5mm | ||
| Max. Hydraulic Force | 31.5MPa | ||
| Power | 380~415VAC kW | ||
