| Name: | Busbar Punching Bending Cutting Machine | Function: | Cutting Punching Bending |
|---|---|---|---|
| Power: | 380~415VAC 50~60Hz 10kW | Piler Head Force (KN): | 300 |
| Max. Hydraulic Force: | 31.5MPa | Bend Force (KN): | 400 KN |
| Punch Force (KN): | 300 KN | Positioning Accuracy: | 0.2mm |
| Max. Bending Width: | 300mm | ||
| High Light: | 400mm Busbar Processing Machine,1800mm Busbar Processing Machine,400 KN Busduct Production Line |
||
High Accuracy One Time Molding Busbar Processing Machine
Features
1. This machine provide the efficiency and guarantee of safety requirement and the design of form a complete set of equipment.
2. The machine is equipped with bending, cutting, punching functionality.
3. Punch holes without burr, cutting surface smooth and cutting angle accurately. it is good for puick and repeat batch procession.
4. High flexibility, small volume, big power, high production capacity and high work efficiency.
5. Safe and firm pedal switch could control oil inlet and oil return.Low noise, harmless processing.
6. Finishing product is beautiful and won’t cause pollution to the environment.
Application
This processor is suitable for making large electric cabinet ,power distribution cabinets ,switch cabinets and power transmission and distribution construction engineering construction site use.Suitable for transmission and distribution in a large workshop and site work, construction, and power distribution cabinets and switch cabinets, etc.
Equipment data on busbar conductor multifunctional processing machine
| No. | Parameters | ||
| Model | KD-DTYTJ-C/A-4.5(6) | ||
|
Force (KN) |
Bend | 400 | |
| Punch | 300 | ||
| Piler Head | 300 | ||
| Stroke of X Axis | 1800mm | ||
| Speed of X Axis | 0~150mm/s | ||
| Marking | Barcode, QR code (optional) | ||
|
Conductor Size (Aluminum, Copper) |
Length | 1200mm~6000mm | |
| Width | 140mm~300mm | ||
| Thickness | 2mm~6mm | ||
| Positioning Accuracy | 0.2mm | ||
| Repetitive Positioning Accuracy | 0.05mm | ||
| Saw Blade Power | 2kW | ||
| Saw Blade Diameter | 400mm | ||
| Max. Bending Width | 300mm | ||
| Max. Bending Height Difference | 40mm | ||
| Max. Hydraulic Force | 31.5MPa | ||
| Power | 380~415VAC 50~60Hz 10kW | ||
Function introduction
By busbar conductor multifunctional processing machine, operator will input values such as length, width, piler position, quantity and etc. to initiate automatic working procedures including ends punching, piler opening, piler punching and etc..
