| Name: | Busbar Punching Bending Cutting Machine | Bend Force (KN): | 400 |
|---|---|---|---|
| Punch Force (KN): | 300 | Piler Head Force (KN): | 300 |
| Power: | 380~415VAC 50~60Hz 10kW | Max. Hydraulic Force: | 31.5MPa |
| Max. Bending Width: | 300mm | Positioning Accuracy: | 0.2mm |
| High Light: | 300mm Busbar Processing Machine,Busbar Processing Machine 400KN,6mm Bar Bending Machine |
||
Automatic Bus Bar Processing Machinery 6mm Copper Bar Cutting Bending Punching Machine
Features:
By busbar conductor multifunctional processing machine, operator will input values such as length, width, piler position, quantity and etc. to initiate automatic working procedures including ends punching, piler opening, piler punching and etc..
Equipment data on busbar conductor multifunctional processing machine
| No. | Parameters | ||
| Model | KD-DTYTJ-C/A-4.5(6) | ||
|
Force (KN) |
Bend | 400 | |
| Punch | 300 | ||
| Piler Head | 300 | ||
| Stroke of X Axis | 1800mm | ||
| Speed of X Axis | 0~150mm/s | ||
| Marking | Barcode, QR code (optional) | ||
|
Conductor Size (Aluminum, Copper) |
Length | 1200mm~6000mm | |
| Width | 140mm~300mm | ||
| Thickness | 2mm~6mm | ||
| Positioning Accuracy | 0.2mm | ||
| Repetitive Positioning Accuracy | 0.05mm | ||
| Saw Blade Power | 2kW | ||
| Saw Blade Diameter | 400mm | ||
| Max. Bending Width | 300mm | ||
| Max. Bending Height Difference | 40mm | ||
| Max. Hydraulic Force | 31.5MPa | ||
| Power | 380~415VAC 50~60Hz 10kW | ||
Function introduction
By busbar conductor multifunctional processing machine, operator will input values such as length, width, piler position, quantity and etc. to initiate automatic working procedures including ends punching, piler opening, piler punching and etc..
Busduct advantage:
Easy and quick installation
Extensive choice of termination elements
Wide adaptability of busduct layout
High Short Circuit Withstand & Low Voltage Drop
Compact Dimensions
100% reusable standard elements
Accessories like tap offs can be fit anywhere along the busbar hence reducing
floor area usage
Lower Down time in case of faults
